Cold-Formed Anchor Channel

Product Details:

Cold-formed anchor channels are specifically designed for use in concrete and masonry structures, providing secure attachment points for anchors, bolts, and other components. They are ideal for a variety of construction applications, offering a reliable solution for securing structural elements without the need for additional reinforcement.

• Built-in Anti-Shear Foot: Some models of cold-formed anchor channels feature an integrated anti-shear foot, which eliminates the need for separate shear reinforcement. This is especially useful in thin panels and low-strength concrete lifts, where additional shear reinforcement might not be practical.

Description and Components:

Design:

Cold-formed anchor channels are typically made from high-quality steel that undergoes a cold-forming process, meaning the material is shaped and formed at room temperature. This process ensures high precision and uniformity in the final product while maintaining excellent structural integrity.

• Material: Cold-formed anchor channels are usually made from steel, including galvanized or stainless steel, depending on the environmental requirements such as corrosion resistance.
• Shape: These channels are formed into a U-shaped profile with pre-drilled holes or slots to allow for easy attachment of bolts or other hardware.

Components:

1. Anchor Body: The main body of the anchor channel, which is embedded into the concrete or masonry. It forms the primary support structure for attaching various elements.
2. Mounting Holes or Slots: Pre-drilled holes or slots in the anchor channel allow for easy installation of anchors, bolts, or brackets.
3. Anti-Shear Foot: Some cold-formed anchor channels come with an integrated anti-shear foot, designed to enhance shear resistance without requiring additional reinforcement.
4. Reinforced Channel Walls: The walls of the channel are designed to provide enhanced load-bearing capacity and resistance to stress.

Functionality:

Installation:

• Embedding in Concrete or Masonry: Cold-formed anchor channels are installed by embedding them into the concrete or masonry during construction. This can be done during the casting of the concrete or by inserting them into pre-formed recesses in the wall or slab.
• Secure Attachment: The pre-drilled holes or slots in the anchor channel provide secure attachment points for bolts, anchors, or other hardware, ensuring the stability of structural components.

Lifting and Handling:

• Cold-formed anchor channels can be used to secure lifting points for prefabricated concrete elements or structural components. They can be installed during the construction phase to allow for easy attachment of lifting slings, chains, or other lifting equipment, facilitating safe and efficient handling.

Applications:

Precast Concrete Industry:
Cold-formed anchor channels are widely used in the precast concrete industry for attaching lifting systems to precast elements, such as panels, beams, and slabs.

Construction and Infrastructure Projects:
These anchor channels are also used in large-scale construction and civil engineering projects, such as building construction, bridges, tunnels, and other infrastructure. They provide strong, reliable anchorage points for securing structural elements during construction and in final installations.

Masonry Construction:
In masonry construction, cold-formed anchor channels can be embedded into brick, stone, or blockwork to provide secure support for fixtures and equipment.

Advantages:

Safety:

1. Cold-formed anchor channels provide secure, reliable anchorage, reducing the risk of failure or detachment during lifting and installation operations.
2. The use of integrated anti-shear feet enhances safety by improving the shear resistance of the channel without the need for additional reinforcement.

Efficiency:

1. The cold-forming manufacturing process ensures precise dimensions, making the channels easy to install and reducing the likelihood of errors.
2. Cold-formed anchor channels streamline the construction process by enabling faster, more accurate placement of anchors and structural components.

Versatility:

1. Cold-formed anchor channels are versatile and can be used in a variety of applications, from securing lifting points in precast concrete to supporting structural elements in masonry or steel construction.
2. Available in different sizes and materials, they can be tailored to meet specific project requirements, including corrosion resistance and load-bearing capacity.
